Hongkong Wine Festival Pagoda Tent For Sale

1. Aluminium Pagoda Tent Application:
The pagoda tent can be widely used for weddings, parties, exhibitions, festivals celebrations, cafe shops, restaurants, corporate events, other events, etc

2. Aluminium Pagoda Tent Specification for the big tents PAG series):

For details, pls refer to the below chart:

  • Mainframe profile size for PAG series: 64.5X64.5X2.5mm (From 3m to 6m) & 120X68X3mm (8m & 10m)
  • Wind load: 80km/h

Minimum tent length: In order to reach the designed wind load and make sure the tent is safety, pls set up the tent with the required minimum tent length.

3. Aluminium Pagoda Tent Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, lining, flooring system, clear PVC windows, ramp, transport rack etc.

Aluminium Pagoda Tent Materials:

  • Fabric: Double PVC coated polyester fabric, 750-900g/sq. M, waterproof, UV resistance, fire retardant according to standard NFPA701, CFM & DIN4102 B1/M2
  • Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
  • Connections: Hot-DIP galvanized

5 Aluminium Pagoda Tent colors available: White, red, yellow, blue, green, black, grey, transparent, etc.

Products certificate:

Fabric: Test reports for the fire retardant, standards: NFPA701, CFM & DIN4102 B1/M2

Structure safety: Certificates by the registered engineers in the U. S. A & Australia.

If the customers need a copy of the above certificate, pls feel free to contact Liri Tent Technology. We will not show them on the website to avoid copies.

Products certificate:

Fabric: Test reports for the fire retardant, standards: NFPA701, CFM & DIN4102 B1/M2
Structure safety: Certificates by the registered engineers in the U. S. A & Australia.

If the customers need the copy of the above certificate, pls feel free to contact Liri Tent Technology. We will not show them on the website to avoid copys.

  • Germany TUV Certificate, SGS, ISO9001: 2008
  • Qualification from Australia
  • Qualification from USA
  • Advanced design and Quality proved

Reputation

  • The first tent manufacturer was established in 1997 in China.
  • The largest tent manufacturer in China covers 30, 000sqm and including 20, 000sqm building area.
  • The most reliable tent supplier. Exported to over 80 countries, and maintaining excellent reputation,
  • being the NO. 1 tent exporter for four years in China.
  • Engineer’s Company, the owner of Liri Tent is more concerned with quality and safety than you.



Model Side Length Bay Eave height Ridge height
PAG3/250 3m unlimited 3m 2.5m 4.3m
PAG4/250 4m unlimited 4m 2.5m 4.8m
PAG5/250 5m unlimited 5m 2.5m 5.43m
PAG6/250 6m unlimited 6m 2.5m 5.92m
PAG8/260 8m unlimited 4m 2.6m 5.36m
PAG10/260 10m unlimited 5m 2.6m 6.38m
